29" Titanium Forks
Thru axle (Images of quick release model)
SPECIFICATION
Torus five-piece titanium forks are light, tough and beautifully crafted. The perfect accompaniment for your rigid mountain bike. Now available with a taper steerer 1.5" - 1 1/8" and a 15mm thru axle, and supplied with a KCNC Thru axle. Available for 26", 27.5" (650B) or 29er bikes. Suspension-corrected sizes based on an 80mm travel fork with 10mm of sag. At 850g, these Ti forks are as light as their carbon equivalents, but provide a little more natural flex, resulting in a much smoother ride. With 36 mm fork legs, these forks are tough too. Must be tried to be believed! Compatible with post mount disc brakes, 160mm minimum rotor size
Materials: Grade 9 Ti-3Al-2.5V alloy tubes, Ti-6Al-4V alloy dropouts
Axle to Crown Length: 26" - 440 mm, 650B - 455 mm, 29er - 470 mm
Fork leg Diameter: 36 mm
Steerer: 1 1/8", or tapered 1.5" - 1 1/8"
QR15 fork supplied with KCNC 15mm Thru axle
Steerer Length: 300 mm
Offset: 45 mm
Brake Mounts: Post Mount Disc
Max Rotor size 185 mm
Rider weight limit : 110kg (240lbs, 17 stone)
Weight: 440 mm - 820g, 455mm - 833g, 470 mm - 850g, 470mm Taper QR15 1120g
Coming Soon!
